OneUp Traction Narrow-Wide Chainring 104 BCD

$55.00
In store: Check availability

Available in store

SKU: 1C0193BLK

OneUp Components' Traction Round Narrow-Wide Chainring keeps your chain on and quiet.

Description

Featuring teeth chamfers, mud is drawn away from the chain and extends chainring life. The included shims also allow compatibility up to 3x drivetrains. For the Oval Switch ring, traction was the priority and OneUp brings this technology to a variety of cranks types.

Features:

  • Get ultimate traction by smoothing out the torque you deliver to your rear tire
  • 12% ovality (32T is equal to a 30T-34T range)
  • 115° clocking from crank arm puts the major axis in your power stroke
  • Narrow Wide tooth profile eliminates chain drop with the perfect chain mesh fit
  • Perfect chainline with built in offset.  For a quieter drivetrain with improved chain wear and best drop performance
  • Reuse your existing 8-10mm long ring hardware. No new bolt packs required
  • Aggressive crud chamfers for awesome mud shedding performance and extended ring life
  • Reinforced Wide tooth design provides maximum ring durability when run without a bash
  • Made from hard wearing 7075-T6 aluminum plate
  • 32T rings have integrated shims and M8 chainring bolt threads
  • 30T rings have integrated shims and M5 chainring bolt threads to allow the smallest ring size possible on a 104 BCD crank. Bolts and spacers included.

Specifications:

  • Material: 7075-T6
  • Weight: 51g (30T), 49g (32T), 51g (34T)
  • Compatible with: 9, 10, 11, and 12 Speed SRAM Chains and 104 BCD cranks (not compatible with 12 Speed XTR Chains)
  • Colors: Black
  • Installation: Align the small bump (small hole on direct mount rings) on the inner edge of the ring with your crank arm
